GS-4554XUP

Product code: 11780022 // MPN: 61884 // EAN: 4044144618840

€7.800,00 (inc. VAT)

Available from 4 to 10 days (6 pcs available)

Add to wishlist

5P TP-Link SG1005P Metall mit 4 PoE-Ports

Code: 25339422

€54,40

Available from 4 to 10 days

Device Type	Switch - 48 ports - L3 - Managed - stackable
Enclosure Type	Desktop, rack-mountable 1U
Subtype	2.5 Gigabit Ethernet
Ports	24 x 100/1000/2.5G (PoE++) + 24 x 10/100/1000 (PoE+) + 4 x SFP+ + 2 x QSFP+
Power Over Ethernet (PoE)	PoE++
PoE Budget	1440 W
Performance	Throughput: 480 Gbps ¦ Maximum packet throughput: 357 Mpps
Capacity	Virtual interfaces (VLANs): 4093 ¦ Packet buffer size: 4 MB ¦ DHCP pool: 16
MAC Address Table Size	32K entries
Jumbo Frame Support	12288 bytes
Routing Protocol	IGMPv2, IGMP, MLDv2, MLD, MSTP, RSTP
Remote Management Protocol	SNMP 1, SNMP 3, SNMP 2c, SSH, ICMP, IPv4, IPv6, TACACS+, RADIUS
Encryption Algorithm	SSL
Features	VLAN support, port mirroring, DiffServ support, MAC address filtering, IP address filtering, firmware upgradable, Quality of Service (QoS), DHCP server, DHCP relay, Port Security, cloud managed, metal housing, Type of Service (ToS), 3 fans, Storm Control, IP source guard, Voice VLAN, Private VLAN Edge (PVE), LANCOM Management Cloud
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qat, IEEE 802.3bj, IEEE 802.1Qav, IEEE 802.3ax, IEEE 802.3bt
Status Indicators	Power, link/activity
[Expansion / Connectivity]
Interfaces	24 x 1000Base-T RJ-45 PoE+ ¦ 24 x 100/1000/2.5G RJ-45 PoE++ ¦ 4 x 1/10Gbit LAN SFP+ ¦ 2 x 1/10Gbit LAN QSFP+
[Power]
Power Device	Internal power supply - hot-plug
Voltage Required	AC 100-240 V (50 - 60 Hz)
Power Consumption Operational	920 Watt
[Miscellaneous]
Included Accessories	2 x 19" mounting brackets
Cables Included	Micro-USB cable - 1 m ¦ Serial cable - 1.5 m
Rack Mounting Kit	Included
Compliant Standards	IC, FCC, ACMA, RFC1213, RFC1493, RFC2674, RFC2460, RFC2863, RFC854, RFC1215, RFC2233, RFC2665, RFC2618, RFC4443, RFC4291, RFC2737, RFC2819, RFC3414, RFC3415, RFC3636, RFC1534, RFC2021, RFC1769, RFC2613, RFC2617, RFC2818, RFC2933, RFC3019, RFC3587, RFC3621, RFC3635, RFC4133, RFC4188, RFC4251, RFC4668, RFC4670, RFC5519, RFC7513, RFC3276
[Software / System Requirements]
OS Required	LCOS SX 5.20
[Dimensions & Weight]
Width	44.2 cm
Depth	44 cm
Height	4.4 cm
Weight	6.3 kg
[Manufacturer Warranty]
Service & Support	Limited warranty - lifetime
[Environmental Parameters]
Min Operating Temperature	0 °C
Max Operating Temperature	40 °C
Humidity Range Operating	10 - 90% (non-condensing)
Min Storage Temperature	0 °C
Max Storage Temperature	50 °C
