NETWORK PCI CARDS

2.5 Gbps
Upgrade your computer to 2.5 Gbps Ethernet.

USB-C connector
Ideal for ultra-thin laptops with USB-C / Thunberbolt 3 connections and no ethernet port.

Install in seconds
Simply plug in the adapter and the built-in driver will be installed in seconds.

Dynamic Power Management
Reduces power consumption during times of light traffic, when idle, or when the Ethernet cable is unplugged.

Upgrade your laptop to 2.5 Gbps Ethernet.
Instantly add multi-Gigabit connectivity to your laptop computer or desktop. Just plug the adapter into an available USB-C port and you’re ready to connect to your router or switch at 2.5x the speed of a standard Gigabit connection.

More than twice as fast as Gigabit Ethernet.
Simply plug into your computer and enjoy fast 2.5 Gigabit Ethernet that allows you to transfer large files in no time, or make light work of backups to a server or network storage device. This reliable adaptor allows you to connect to multi-gigabit speeds instantly, perfect for network intensive workloads.

Easy to install and use.
Simply plug the adapter into an available USB-C port. The installation software is already preloaded on the adapter, so there’s no need for CDs or downloads1. The portable compact design lets you easily slip the adapter into your pocket or laptop bag and take it with you anywhere.

Green technology that saves energy.
Power to the adapter is provided directly from the USB Type-C port and not only supports the USB 3.0 standard’s power-saving features, but also includes an energy-saving suspend and resume function to minimise power consumption when network traffic is light, the device is idle, or when the Ethernet cable is unplugged. Good for the environment, and ever better for your device’s battery life.

Works with existing networks.
The DUB-E250 is fully backwards compatible with existing Fast Ethernet or Gigabit networks, allowing you to connect to a wired network wherever you are.

Ports & interfaces
Connectivity technology: Wired
Host interface: USB Type-C
Interface: Ethernet
Ethernet LAN (RJ-45) ports: 1
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
Network
Maximum data transfer rate: 2500 Mbit/s
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000,2500 Mbit/s
Auto MDIX IEEE: Yes
Full duplex: Yes
VLAN tagging: Yes
Design
Product colour: White
Internal: No
Hot-Plug support: Yes
Plug and Play: Yes
LED indicators: Yes
Certification: CE, FCC, IC
Power
Power consumption: 250 mA
USB powered: Yes
System requirements
Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Operational conditions
Operating temperature (T-T): 10 - 45 °C
Storage temperature (T-T): 10 - 70 °C
Operating relative humidity (H-H): 10 - 85%
Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 21.5 mm
Depth: 53 mm
Height: 15 mm
Weight: 28.5 g
Logistics data
Harmonized System (HS) code: 85176990
Other features
Flow control support: Yes
Cable length: 0.16 m
