SWITCHES

POWER AND THROUGHPUT
Edge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant

NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.

FAST, EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.

DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

Management features
Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
10G Ethernet (copper) ports quantity: 24
SFP+ module slots quantity: 8
SFP28 ports quantity: 8
Network
Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u
10G support: Yes
Full duplex: Yes
Policy-based routing: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
6to4 tunnel: Yes
IPv4 routes: 512
IPv6 routes: 256
VLAN support: Yes
Virtual LAN features: MAC address-based VLAN, Private VLAN, Voice VLAN
Number of VLANs: 4093
Data transmission
Switching capacity: 1040 Gbit/s
Throughput: 773.76 Mpps
MAC address table: 16000 entries
Store-and-forward: Yes
Latency (10 Gbps): 2.7 µs
Jumbo frames support: Yes
Jumbo frames: 12000
Packet buffer memory: 64 MB
Security
DHCP features: DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
Access Control List (ACL): Yes
Access Control List (ACL) egress: 1023
Access Control List (ACL) ingress: 511
IGMP snooping: Yes
IGMP proxy: Yes
MAC address filtering: Yes
Static port security: Yes
Loop protection: Yes
BPDU filtering/protection: Yes
Authentication: Guest VLAN, MAC-based authentication
Root protection: Yes
Password protection: Yes
DoS attack prevention: Yes
Authentication type: RADIUS, TACACS+
Queue scheduling algorithms: Strict Priority Queue (SPQ), Weighted random early detection (WRED)
Multicast features
Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Y
Protocols
Management protocols: SNMP V1, V2, V3
GARP VLAN Registration Protocol (GVRP): Yes
Routing protocols: OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2
Design
Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Product colour: Black
LED indicators: Yes
Airflow direction: Front-to-back airflow
Performance
Built-in processor: Yes
Processor model: ARM Cortex-A57
Processor frequency: 1800 MHz
Memory type: DDR4-SDRAM
Internal memory: 4096 MB
Flash memory: 512 MB
sFlow: Yes
Power
Power source: AC
Power supply included: Yes
Power consumption (typical): 151.8 W
Power consumption (max): 464 W
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet 4PPoE (PoE++) ports quantity: 24
Power over Ethernet (PoE) power per port: 90 W
Total Power over Ethernet (PoE) budget: 1770 W
Other features
Power supply: 750 W
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 3000 m
Weight & dimensions
Width: 440 mm
Depth: 400 mm
Height: 43.2 mm
Weight: 7.24 kg
Packaging content
Cables included: AC, USB Type-C
Quick start guide: Yes
Rack mount kit: Yes
Packaging data
Included power plug types: EU, UK, NA
Sustainability
Sustainability compliance: Yes
Certificates
Compliance certificates: BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
