SERVERS

Processor
Built-in processor: No
Motherboard chipset: AMD B650
Processor socket: Socket AM5
Processor family: AMD
Number of processors supported: 1
Compatible processor series: AMD EPYC
Memory
Number of DIMM slots: 4
Supported memory types: DDR5-SDRAM
Maximum internal memory: 192 GB
Supported UDIMM clock speeds: 5200 MHz
Memory voltage: 1.1 V
ECC: Yes
Storage
Number of storage drives supported: 8
Hot-swap HDD bays: Yes
Storage drive sizes supported: 3.5"
Supported storage drive types: HDD & SSD
Network
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
LAN controller: Intel I210
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 3
Ethernet LAN (RJ-45) ports: 3
IPMI LAN (RJ-45) port: Yes
VGA (D-Sub) ports quantity: 1
Expansion slots
PCI Express slots version: 4.0, 5.0
PCI Express x16 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 2
Features
PC health monitoring: CPU, Fan, LED, Temperature
Integrated BMC with IPMI: Yes
Backplanes support: Yes
Technical details
Compliance certificates: RoHS
Processor special features
Intelligent Platform Management Interface (IPMI) support: Yes
BIOS
BIOS type: AMI
BIOS memory size: 32 Mbit
Design
Chassis type: Rack (2U)
Product colour: Black
LED indicators: Fan fail, HDD, LAN, Power
On/off switch: Yes
Reset button: Yes
Number of fans: 3 fan(s)
Fan diameter: 8 cm
Power
Power supply: 800 W
Redundant power supply (RPS) support: Yes
Number of redundant power supplies installed: 1
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Operational conditions
Operating temperature (T-T): 10 - 35 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 8 - 90%
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 437 mm
Depth: 647 mm
Height: 89 mm
Weight: 16.8 kg
Power supply dimensions (WxDxH): 76 x 336 x 40 mm
Packaging data
Package weight: 16.8 kg
