DIGITAL SIGNAGE

Built to perform, designed to last

The versatile solution for professional display applications, the Sharp MultiSync® M2 Series (32" up to 98") is purpose-built for demanding signage and meeting room environments. With native USB-C connectivity and broad compatibility with platforms such as Crestron, Cisco Webex, and Microsoft Teams, it enables seamless BYOD collaboration and future-ready integration, while 802.1x LAN support ensures enterprise-grade network security. Featuring class-leading 550 cd/m² brightness, a high-haze panel to minimise glare, and NEC’s trusted SpectraView Engine, the M2 Series delivers outstanding visual performance with unmatched colour precision.

As part of the new Sharp-branded display family, the MultiSync® M2 Series builds on NEC’s legacy of quality and reliability to drive greater efficiency and long-term value. Its proven modular design supports custom computing options (Raspberry Pi or Intel® SDM) and flexible connectivity (e.g. AV-over-IP), ensuring lasting versatility, performance, and sustainability.

Display
Panel type: VA
LED backlight: Yes
LED backlighting type: Direct-LED
Display diagonal: 127 cm (50")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 550 cd/m²
HD type: 4K Ultra HD
Touchscreen: No
Native aspect ratio: 16:9
Contrast ratio (typical): 8000:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.073 billion colours
Pixel pitch: 0.285 x 0.285 mm
Active display area (W x H): 1095.8 x 616.4 mm
Display diagonal (metric): 125.7 cm
Maximum frame rate: 60 fps
Haze rate: 25%
RGB colour space: NTSC
Ports & interfaces
HDMI ports quantity: 3
HDMI input ports quantity: 2
HDMI output ports quantity: 1
DVI port: No
DisplayPorts quantity: 2
DisplayPorts in: 1
DisplayPorts out: 1
USB port: Yes
USB ports quantity: 4
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type: USB Type-A, USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB Power Delivery (USB PD): Yes
USB Power Delivery up to: 65 W
Ethernet LAN (RJ-45) ports: 2
RS-232C: Yes
Audio
Built-in speaker(s): Yes
Number of built-in speakers: 2
RMS rated power: 20 W
Design
Product design: Digital signage flat panel
Product colour: Black
VESA mounting: Yes
Panel mounting interface: 300 x 300 mm
Bezel width (bottom): 1.39 cm
Bezel width (side): 1.09 cm
Bezel width (top): 1.09 cm
Performance
Operating hours (hours/days): 24/7
International Protection (IP) code: IP5X, IP2X
Power
Power consumption (typical): 85 W
Power consumption (standby): 2 W
Power consumption (off): 0.5 W
Energy efficiency class (SDR): G
Energy consumption (SDR) per 1000 hours: 81 kWh
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Energy efficiency scale: A to G
Computer system
Computer system: No
Built-in processor: No
Weight & dimensions
Display width: 1121.6 mm
Display depth: 66.5 mm
Display height: 645.2 mm
Display weight: 18 kg
Packaging data
Package width: 1245 mm
Package depth: 188 mm
Package height: 785 mm
Package weight: 23 kg
Packaging content
Remote control included: Yes
Batteries included: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 20 - 80%
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 10,100 Mbit/s
Features
Base material: Metal
