ROUTERS

Get Your Home Ready for WiFi 6 (802.11ax)
The growing number of connected personal and IoT devices has led to an overall increase in network density that is pushing the limits of the current WiFi standard. The latest 802.11ax standard provides future-proof technologies, higher network efficiency, faster WiFi speeds, greater coverage and improved battery life for connected devices, providing a significantly better networking experience for users.
*It requires 802.11ax-compatible devices to enjoy the benefits brought by 802.11ax WiFi standard.

Next-Gen WiFi Speed
RT-AX53U is a 2x2 dual-band WiFi router that provides 80MHz bandwidth and 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 1800Mbps — 574Mbps on the 2.4GHz band and 1201Mbps on the 5GHz band — RT-AX53U is 1.5X faster than 802.11ac 2x2 dual-band routers.

Built for Multi-device Households
With a revolutionary combination of OFDMA and MU-MIMO technology, 802.11ax technology provides up to 4X greater network capacity and efficiency in traffic-dense environments. Previous-generation 802.11ac WiFi can only handle one device at a time on each network channel, which is an inefficient use of available bandwidth. OFDMA support in the 802.11ax WiFi standard divides each channel into small sub-channels, allowing signals from multiple devices* to be bundled together and transmitted simultaneously, reducing latency for a smoother, more responsive WiFi experience.

Better Battery Life for Your Devices
Target Wake Time (TWT) allows RT-AX53U to schedule designated intervals for devices to transmit data. This allows them to sleep when there is no need to wait for a router signal, reducing power consumption by up to 7X for significantly improved battery life*.

WiFi that Goes Farther
With the latest 802.11ax WiFi standard featuring OFDMA technology, RT-AX53U provides increased WiFi signal range and better coverage by dividing each channel into smaller sub-channels. These sub-channels have a smaller bandwidth that enables them to travel up to 80% farther1, resulting in a better WiFi connection throughout your home*.

Protection for your Home Network
RT-AX53U incorporates ASUS AiProtection, a commercial-grade network security system powered by Trend Micro™ Smart Home Network. With AiProtection, all connected devices are protected, even if they have no antivirus capability of their own — such as IoT devices. AiProtection blocks common internet-based attacks before they reach the network, and if an infected device is detected on the network, AiProtection instantly blocks it to prevent it sending any personal information to malicious servers.

Connectivity Options
RT-AX53U has one Gigabit WAN port, three Gigabit LAN ports, and USB 2.0 port*. Smart TV, game consoles, NAS storage devices, backup internet and more can now have their own dedicated ports, making RT-AX53U your solid digital home hub.

Robust control and optimization with ASUSWRT
With the ASUSWRT dashboard UI, setup, monitor, and control network applications all in one intuitive area. With fast setup, multi-device detection, and flexible settings, ASUSWRT makes the most of your network performance.
*xActual data throughput and WiFi coverage will vary from network conditions and environmental factors, including the volume of network traffic, building material and construction, and network overhead, result in lower actual data throughput and wireless coverage.

WAN connection
Ethernet WAN: Yes
DSL WAN: No
SIM card slot: No
3G/4G USB modem compatibility: Yes
WAN connection type: RJ-45
Wireless LAN features
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Network
Ethernet LAN: Yes
Ethernet LAN interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Dynamic DNS (DDNS): Yes
VPN support: VPN Client L2PT VPN Client OVPNVPN Client PPTPVPN Server IPSecVPN Server OVPNVPN Server PPTPVPN Fusion
Mobile network
3G: Yes
4G: Yes
5G: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
USB port: Yes
USB 2.0 ports quantity: 1
Memory card slot(s): No
Management features
Bandwidth control: Yes
Quality of Service (QoS) support: Yes
Wireless statistics: Yes
Reset button: Yes
WPS push button: Yes
MU-MIMO technology: Yes
Security
Security algorithms: SSH, WPA, WPA2, WPA2-Enterprise, WPA3
Firewall: Yes
Guest access: Yes
Parental control: Yes
MAC address filtering: Yes
DMZ support: Yes
Protocols
DHCP server: Yes
Design
Product colour: Black
Indication light: Yes
LED indicators: LAN, Power, USB, WAN
On/off switch: Yes
Product type: Tabletop router
Antenna
Antenna design: External
Antenna gain level (max): 2 dBi
Antennas quantity: 4
Detachable antenna(s): Yes
Features
Built-in processor: Yes
Internal memory: 256 MB
Flash memory: 128 MB
Works with Amazon Alexa: Yes
Power
Power source type: AC, DC
AC input voltage: 110 - 240 V
AC input frequency: 50 - 60 Hz
Output voltage: 12 V
Output current: 1.5 A
Weight & dimensions
Weight: 346 g
Logistics data
Harmonized System (HS) code: 85176990
