What This Product Does
TL-SF1008P is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to ­fix devices such as APs, IP Cameras or IP Phones, etc.

Power over Ethernet
4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

-Overload Arrangement
TL-SF1008P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 57W, a priority will be arranged among the PoE ports, then the system will cut o‑ the power of the lowest-priority port.

-Port Priority Function
Priority (port-1=port-2=port-3>port-4): This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 57W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.

Easy To Use
TL-SF1008P is easy to install and use. It requires no confi­guration and installation. With desktop design, outstanding performance and quality, the TP-LINK’s TL-SF1008P 8-Port 10/100Mbps Desktop Switch with 4-Port PoE is an ideal choice for expanding your home or office network.

Management features
Switch type: Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity: 8
Power connector: DC-in jack
Network
Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
10G support: No
Copper ethernet cabling technology: 10GBASE-T, 100BASE-TX
Cable types supported: Cat3, Cat4, Cat5, Cat5e
Full duplex: Yes
Half duplex: Yes
Flow control support: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
MAC address auto-aging supported: Yes
Data transmission
Switching capacity: 1.6 Gbit/s
Forwarding rate: 1.1904 Mpps
MAC address table: 2000 entries
Store-and-forward: Yes
Protocols
IPv4 & IPv6 features: IPv6 portal
Design
Rack mounting: No
Stackable: No
Product colour: Black
Housing material: Metal
LED indicators: Yes
Wall mountable: Yes
Performance
Fanless: Yes
Power
Power source: DC/PoE
Power supply included: No
AC input voltage: 220 V
AC input frequency: 50 Hz
DC input voltage: 53.5 V
Input current: 1.31 A
Power consumption (max): 66 W
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 8
Total Power over Ethernet (PoE) budget: 57 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 248.93 BTU/h
Weight & dimensions
Width: 171 mm
Depth: 98 mm
Height: 27 mm
Packaging content
User guide: Yes
Packaging data
AC adapter included: Yes
Package type: Box
Package width: 223 mm
Package depth: 280 mm
Package height: 68 mm
Package weight: 970 g
Sustainability
Sustainability compliance: Yes
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
Logistics data
Harmonized System (HS) code: 85176990
