Casview Video Balun over CAT5 (SET) CPB-H223C 8MP

Κωδικός: 27160820 // Κωδικός προμηθευτή: CPB-H223C

Νέο προϊόν

€5,94 (συμπ. ΦΠΑ)

Διαθέσιμο από 1-3 εργάσιμες ημέρες

Προσθήκη στη wishlist

Παρόμοιο προϊόν

Casview POE Adaptor over ethernet (SET)

Κωδικός: 25118920

€5,94

Διαθέσιμο από 1-3 εργάσιμες ημέρες

Compatible with all HD-CVI/ HD-TVI/ HD-AHD & CVBS
Up to 450m for 720P CVI Cameras
Up to 250m for 1080P/ 3MP/ 4MP/ 5MP/8MP CVI Cameras
Up to 250m for 720P/ 1080P/ 3MP/ 4MP/ 5MP/8MP TVI Cameras
Up to 350m for 720P/ 960P AHD Cameras
Up to 250m for 1080P/ 3MP/ 4MP/ 5MP/8MP AHD Cameras
NTSC, PAL and SECAM video formats
No power required
60dB crosstalk and noise immunity
Compact size and easy installation
Built in transient suppression protection
innovative combinable design

Balun Type : Passive
Video transmitting distance : Up to 450m for 720P CVI Cameras / Up to 250m for 1080P/ 3MP/ 4MP/ 5MP/8MP CVI Cameras / Up to 250m for 720P/ 1080P/ 3MP/ 4MP/ 5MP/8MP TVI Cameras / Up to 350m for 720P/ 960P AHD Cameras / Up to 250m for 1080P/ 3MP/ 4MP/ 5MP/8MP AHD Cameras
Video Formats : NTSC, PAL, SECAM
Crosstalk & noise immunity : 60dB
Surge protection : 4KV, ESD:8KV
Frequency Response : DC to 60Mhz
Wire Type : Unshielded Cat-5 or above twisted pair wire
Impedance : BNC:75 ohms; Terminal: 100 ohms
Working temperature : -10°C to +70°C
Storage Temperature : -10°C to +70°C
Humidity : 0 to 95%
Material : ABS engineering plastic
