Gigabyte B850 AORUS ELITE WF7 ICE AM5

Product code: 27450222 // MPN: B850 AORUS ELITE WF7 ICE // EAN: 4719331866099

New entry

€311,30 (inc. VAT)

Available from 3 to 6 business days (6 pcs available)

Add to wishlist

Gigabyte Z790 AORUS ELITE AX LGA 1700

Code: 17332122

€316,55

Available from 3 to 8 business days

The Gigabyte B850 AORUS ELITE WF7 ICE AM5 is a motherboard. It also offers socket Socket AM5 and 4 memory slots. Finished in brown, white. Designed to deliver reliable performance and quality.

Processor manufacturer: AMD
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets: Socket AM5
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Memory channels: Dual-channel
ECC сompatibility: Non-ECC
Supported memory clock speeds: 4400,4800,5200,5600,5800,6000,6200,6600,6800,7000,7200,7400,7600,7900,7950,8000,8200 MHz
Supported memory clock speed (max): 8200 MHz
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Maximum internal memory per slot: 64 GB
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 4
Number of storage drives supported: 7
RAID support: Yes
RAID levels: 0, 1, 10
Parallel processing technology support: Not supported
On-board graphics card: No
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
DirectX version: 12.0
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 3.2 Gen 2x2 connectors: 1
Number of SATA III connectors: 4
Total number of SATA connectors: 4
Front panel audio connector: Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Number of CPU fan connectors: 2
Number of chassis fan connectors: 3
EPS power connector (8-pin): Yes
Number of EPS power connectors (8-pin): 1
TPM connector: Yes
Serial port headers: 1
12V power connector: Yes
Number of water pump connectors: 2
RGB LED pin header: Yes
Number of RGB LED pin headers: 4
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
HDMI version: 1.4
DisplayPorts quantity: 1
DisplayPort version: 1.4
Headphone outputs: 1
Microphone in: Yes
WiFi-AP antenna jack: 2
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN controller model: Realtek RTL8922AE
Bluetooth: Yes
Bluetooth version: 5.4
Motherboard chipset: AMD B850
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Product colour: Brown, White
PC health monitoring: Fan, Temperature, Voltage, Water cooling
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: AMD
Power source type: ATX
Windows operating systems supported: Windows 10 x64, Windows 11 x64
PCI Express x16 (Gen 4.x) slots: 2
Number of M.2 (M) slots: 3
1st M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
ACPI version: 5.0
Clear CMOS jumper: Yes
Clear CMOS button: Yes
System Management BIOS (SMBIOS) version: 2.7
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Package width: 335 mm
Package depth: 270 mm
Package height: 80 mm
Package weight: 2.46 kg
Width: 305 mm
Depth: 244 mm
Height: 35 mm
Batteries included: Yes
Antenna included: Yes
Screws included: Yes
Bundled software: Norton Internet Security (OEM version)LAN bandwidth management software
Weight: 2.16 kg
Warranty period: 3 year(s)

Bluetooth Version:	Bluetooth 5.4
Color:	Brown, White
CPU Brand:	AMD
Ethernet LAN Ports:	1
Memory Slots:	4
Processor Socket:	Socket AM5
Resolution:	4K DCI
