SWITCHES

Management features
Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes
Cloud-managed: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Network
Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
10G support: No
Port mirroring: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Auto MDI/MDI-X: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto-negotiation: Yes
VLAN support: Yes
Virtual LAN features: MTU VLAN, Port-based VLAN, Tagged VLAN
Number of VLANs: 4000
Optical fiber
Transmission distance (max): 0.25 km
Data transmission
Switching capacity: 16 Gbit/s
Forwarding rate: 11.904 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 15000
Packet buffer memory: 0.5 MB
Security
DHCP features: DHCP client
IGMP snooping: Yes
Loop protection: Yes
Multicast features
Multicast support: Yes
Design
Rack mounting: Yes
Form factor: DIN rail
Product colour: Black
LED indicators: Yes
Power
Power source: DC
DC input voltage: 53 V
Input current: 1.31 A
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: PoE+
Power over Ethernet plus (PoE+) ports quantity: 8
Total Power over Ethernet (PoE) budget: 64 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 158 mm
Depth: 100.7 mm
Height: 25.4 mm
Packaging content
Cables included: Power
Quick start guide: Yes
Certificates
Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
