SCANNERS

The Xenon Ultra family of handheld scanners is a premium evolution of the widely known legacy Xenon and Xenon XP general purpose scanners, taking our industry-leading scan performance and reliability one step further.

- The Xenon Ultra scanners are designed with green-dot LED aimers, helping users ensure accurate scans with each use.
- Warm-white illumination and print contrast down to 15% enables users to capture ultra high-density barcodes, even down to 2 mils.
- The green-dot LED aimer and white illumination aids in easier targeting and enhances scan accuracy on high-density and low-quality codes in high-throughput environments.
- With added IR capabilities, reduce annoying false activations, enabling illumination only when needed. IR even helps to reduce the gap between point-and-shoot and hands-free modes of operations.

Scanning
Type: Handheld bar code reader
Scanner type: 1D/2D
Linear (1D) barcodes supported: Code 128, Code 39, PDF417, U.P.C.
2D (matrix & stacked) barcodes supported: Code 39, Data Matrix, QR Code
Optical sensor resolution (W x H): 1280 x 800 pixels
Light levels (direct sunlight): 0 - 100000 lx
Wavelength: 525 nm
Ports & interfaces
Connectivity technology: Wired
Standard interfaces: Keyboard wedge, RS-232, USB
Performance
International Protection (IP) code: IP52
Product colour: Black
Power
Power source type: Battery
Battery technology: Lithium-Ion (Li-Ion)
Battery capacity: 3300 mAh
Input voltage: 4.4 - 5.5 V
Weight & dimensions
Width: 108.2 mm
Depth: 70.4 mm
Height: 160.2 mm
Weight: 247 g
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
