POWER SUPPLY (PSU)

• AC input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• Input current: 10 A
• Power Factor Correction (PFC) type: Active
• Combined power (+3.3V): 120 W
• Combined power (+12V): 850 W
• Combined power (+5V): 120 W
• Combined power (-12V): 3.6 W
• Combined power (+5Vsb): 15 W
• Max output current (+3.3V): 22 A
• Max output current (+12V): 70.9 A
• Max output current (+5V): 22 A
• Max output current (-12V): 0.3 A
• Max output current (+5Vsb): 3 A
• Motherboard power connector: 24-pin ATX
• Motherboard power cable length: 60 cm
• Number of SATA power connectors: 9
• SATA power cable length: 150,500 mm
• Peripheral (Molex) power cable length: 150,500 mm
• PCI Express power connectors (6+2 pin): 4
• PCI Express power cable length: 50 cm
• CPU power connector (4+4 pin): Yes
• CPU power cable length: 65 cm
• Floppy drive power connector: 1
• Floppy disk drive connector: Yes
• Floppy disk drive cable length: 15 cm
• PCI Express connector: Yes
• Cabling type: Fully-Modular
• Silent mode: Yes
• Bearing technology: HDB
• Mean time between failures (MTBF): 100000 h
• Product colour: Black
• Cooling type: Active
• Fan diameter: 14 cm
• Number of fans: 1 fan(s)
• Illumination: Yes
• On/off switch: Yes
• Operating temperature (T-T): 0 - 40 °C
• Storage temperature (T-T): -40 - 70 °C
• Operating relative humidity (H-H): 20 - 90%
• Storage relative humidity (H-H): 5 - 95%
• Cables included: AC, CPU, Peripheral (Molex), SATA
• Harmonized System (HS) code: 84733020
